- True R.M.S. 3-phase voltage measuring for both Source 1 and Source 2
- True R.M.S. 3-phase load current/power
- Software configurable for wide range of ATS applications:
      - Utility-to-Generator: Utility is preferred with a generator as                    emergency source
      - Generator-to-Generator: One genset is preferred with a second           genset as backup
      - Utility-to-Utility: Utility is preferred with second utility as the                   emergency source
- Incorporates several monitoring features for a secure transfer: Source, Load, Switch, Battery, In-phase, and parallel time monitor
- Intelligent limit switch feedback monitoring to ensure plausibility before initiating a transfer
- Fully configurable transfer command pulse configuration
- Inhibit transfer to S1, S2, both or start emergency source but initiate no transfer
- Elevator pre-signal with timer before carrying out a transfer
- Motor load disconnect signal with timer and possibility to daisy chain multiple MLDs for load sequencing
- Source priority selection configurable via LogicsManager
- Load test and engine test to initiate routine health check of the emergency source
- In-phase monitoring ensures a transfer occurs within a phase angle difference of 70 or less
- Extended parallel time enables soft loading applications
- Vector group adjustment if transformers are used in the ATS system
- Shunt trip enable signal ensures both sources are not paralleled for more than desired time
- Remote control via interface (CANopen, Modbus RTU) and via discrete inputs
- I/O expansion capability (additional 16x DI and 16x DO supported via IKD1M or 3rd party modules)
- Adjustable display backlight shutdown to reduce power consumption
- Woodward ToolKit™ software for flexible setup from a single connection to the network. Supports settings file created from the DTSC-200
