Five-way three-wire PT100 temperature sensors, providingreal-time temperature detection and protection；

Network port for remote parameter reading, configuration and real-time data monitoring；

USB flash drive recording function allows for data analysis by opening the record via PC software；

Functions of over-excitation limit, under-excitation limit, stator current limit, U/F limit；

Soft start function is fitted for automatic voltage regulation(AVR) and field current regulation (FCR) modes；

PID algorithm for excitation regulation and parameters of four modes are independent；

Adjusting output target value via digital input, analog voltage input, analog resistance input, and CAN communication；

The secondary rated current of CT can be set as 5A or 1A；

Functions of load compensation, droop and transmission linevoltage drop compensation；

Bluetooth communication port for parameter reading, configuration and real-time data monitoring via mobile APP；

Detect generator voltage harmonic THDu, generator current harmonic THDi, and 1st-31st harmonic；

Real-time data curve analysis can be realized by PC software or mobile APP；

Protection detection and alarm function for voltage frequency, current, power, etc.；

Running data record function. Voltage regulator can recordrunning data once per second, and 8192 pieces of runningdata can be saved as CSV file via PC software；

Real-time clock and event log, which can loop record 999 logs；

Black box function enables to loop record 5 groups of faultalarm data, each group includes 60 pieces of detailed datafrom 50s before and 10s after fault alarm occurs.
